Vinyl Horizontal Privacy Fence Panel w/Lattice Top, 8ft height 6ft width, White
Pemberton CollectionWhite never picks up a metal insert in this Pemberton panel, not in the top rail, not the bottom, not at any height, and that holds true at this tallest 8-foot size too.
What grows instead is the lattice crown: the solid board section stops at 6 feet, and the extra 2 feet above it is open diamond lattice, so this panel reads taller and more open on top rather than just taller overall. Where a 6-foot line still lets neighbors see in, the taller lattice closes that gap. Get a free quote on White vinyl fencing.
All materials are sourced and manufactured in the United States.
What's Included
Each kit ships with the components below, pre-cut to size.
| Component | Specification | Quantity |
|---|---|---|
| Post | 5in x 5in, L-120in | Qty (2) |
| Rail (Top) | Hollow Rail 2in x 3.5in, L-65in | Qty (1) |
| Rail (Middle) | Pocket Rail 1.75in x 8in, L-65in | Qty (1) |
| Rail (Bottom) | Pocket Rail 1.75in x 8in, L-65in | Qty (1) |
| T&G Panels | 7/8in x 11.3in, L-62in | Qty (6) |
| U-Channel (for bottom T&G) | 7/8in, L-54in | Qty (2) |
| U-Channel (for Acrylic) | 1in x 1in, L-20.5in | Qty (2) |
| Post Caps | External 5in x 5in | Qty (2) |
| Lattice Strip | 1.125in Small Diamond 48in x 62in | Qty (1) |
Customize Your Panel
Pick the color and height that match your project. Selections preview instantly.
We partnered with Synchrony so a new fence doesn't have to wait on the whole budget. Zero down, low monthly payments, and flexible terms, all on approved credit. Pick the panels you want, get them installed now, and spread the cost over months that work for you. Here's how our financing works, terms and application included.
-
Eco-Friendly
-
Lifetime Warranty
-
High Quality Materials
-
Durability Materials
Pemberton Vinyl Horizontal Privacy Fence Panel, White, 8 ft, 6 ft Wide
At 8 feet, this is the tallest size in the Pemberton line, and the extra height over the 7-foot panel comes entirely from the lattice crown, not the solid section.
The board portion caps out at 6 feet across every Pemberton height from 6 ft up, so an 8-foot panel is 6 feet of solid horizontal board plus a 2-foot lattice top, doubled from the 1-foot crown on the shorter sizes. That taller diamond-lattice band is what carries the extra coverage, not more solid boards.
Posts run 5×5 inches at 120 inches long, the longest in the line, set in soil or concrete. Top, bottom, and middle rails hold the frame at 65 inches each, and six tongue-and-groove boards fill the 6-foot solid section, the same count as the 7-foot panel.
The picket U-channel around the lattice runs 20.5 inches here, more than double the 8.5 inches on the shorter panels, matching the taller 2-foot crown. White adds no metal insert to any of these rails.
White, Tan, and Clay make up the Standard Solid palette here, spread over four heights, 5 to 8 feet, all at a fixed 6-foot width; Pemberton does not go below 5 feet into topper sizes. White’s color runs through the vinyl rather than sitting on the surface as paint. Among the three colors, this is the one built without any metal-insert reinforcement, at 8 feet and at every shorter size too.
The vinyl itself is US-made, UV-protected, and water resistant, so it needs no paint or stain and holds up to sun without yellowing; a rinse now and then is the extent of the upkeep. White carries a transferable limited lifetime warranty on the material, backed by PVAF’s own 5-year workmanship warranty on the install.
Matching White gates are available for this style, and PVAF fabricates custom heights and widths for runs this 8-foot, 6-foot-wide section does not fit. Get a free quote on White vinyl fencing.
Panel Details
- Panel Style
- Privacy Horizontal w/Lattice-Top
- Collection
- Pemberton
- Nominal Panel Height
- 8 feet
- Actual Panel Height
- 96 inches
- Nominal Panel Width
- 6 feet
- Actual Panel Width
- 72 inches
- Proportional Split
- 6ft+2ft
- Color
- White
- Color Family
- Standard Solid
- Post Contact Type
- Soil or Concrete
- Warranty
- Transferable Limited Lifetime Warranty
- Features
- UV Protected, Water Resistant
- Material
- Vinyl (PVC)
- Origin
- United States 🇺🇸
