Vinyl Horizontal Privacy Fence Panel w/Horizontal Picket Top, 5ft height 6ft width, Clay
Riverstone Horizontal CollectionFull reinforcement, metal inserts filling the top, bottom, and middle rails plus two of the three tongue-and-groove boards, makes Clay the toughest build available at Riverstone’s shortest 5-foot height, a 4-foot solid horizontal base under a 1-foot decorative picket top.
Clay’s deep, terracotta-leaning tone runs through the vinyl rather than coating the surface, holding its color without a repaint. Sized for a side yard or a shorter line rather than the taller heights built for overlooked lots. A free PVAF quote follows your measurements.
All materials are sourced and manufactured in the United States.
What's Included
Each kit ships with the components below, pre-cut to size.
| Component | Specification | Quantity |
|---|---|---|
| Post | 5in x 5in, L-84in | Qty (2) |
| Rail (Top) | Hollow Rail 2in x 3.5in, L-65in | Qty (1) |
| Rail (Middle) | Pocket Rail 1.75in x 8in, L-65in | Qty (1) |
| Rail (Bottom) | Pocket Rail 1.75in x 8in, L-65in | Qty (1) |
| Accent Pickets | 7/8in x 1.5in, L-65in | Qty (3) |
| T&G Panels | 7/8in x 11.3in, L-62in | Qty (3) |
| U-Channel (for bottom T&G) | 7/8in, L-30in | Qty (2) |
| Post Caps | External 5in x 5in | Qty (2) |
| Metal Insert (Top Rail) | 2in x 3.5in, L-65in | Qty (1) |
| Metal Insert (Bottom Rail) | 1.75in x 8in, L-65in | Qty (1) |
| Metal Insert (Middle Rail) | 1.75in x 8in, L-65in | Qty (1) |
| Metal Insert (T&G) | 7/8in, L-62in | Qty (2) |
Customize Your Panel
Pick the color and height that match your project. Selections preview instantly.
We partnered with Synchrony so a new fence doesn't have to wait on the whole budget. Zero down, low monthly payments, and flexible terms, all on approved credit. Pick the panels you want, get them installed now, and spread the cost over months that work for you. Here's how our financing works, terms and application included.
-
Eco-Friendly
-
Lifetime Warranty
-
High Quality Materials
-
Durability Materials
Riverstone Clay Vinyl Horizontal Privacy Fence Panel, 5 ft H x 6 ft W
Clay is the fully reinforced option in Riverstone’s three-color lineup, metal inserts running through the top rail, bottom rail, and middle rail, plus two of the three tongue-and-groove boards, at every height this style ships, including this 5-foot base size. The panel measures 60 by 72 inches on 5 by 5 posts cut to 84 inches.
That full build sits on the same 4-foot solid base and 1-foot picket top every 5-foot Riverstone color shares: three horizontal T&G boards, 7/8 by 11.3 inches, locked edge to edge across a three-rail frame, with three spaced accent pickets over a 30-inch bottom U-channel.
White ships this style with no metal insert at all, and Tan adds one to the bottom rail only; Clay carries reinforcement into the rails and the boards together, the sturdiest frame at this height. The deep, terracotta-leaning tone runs through the vinyl rather than sitting on top as a coating, holding its color without a repaint.
The picket top remains decorative rather than a privacy element on every Riverstone color, Clay included: its pickets sit spaced apart instead of interlocking, so light passes while the solid T&G base below carries the screening. Ashford’s horizontal panel is fully solid with no top accent, Kingston’s horizontal style flips the pickets vertical, and Riverstone’s vertical-bodied sibling stands its boards upright.
Between the deeper color and the sturdiest frame in the lineup, this 5-foot Clay build is the toughest option at Riverstone’s shortest height, fitted to a side yard rather than the 7 to 8-foot heights meant for overlooked lots.
PVAF stands behind the vinyl with a transferable limited lifetime warranty on top of its own 5-year workmanship warranty on installation. Custom sizing and a matching clay gate are available, and measurements sent to PVAF bring back a free quote.
Panel Details
- Panel Style
- Privacy Horizontal w/Picket-Top Horizontal
- Collection
- Riverstone Horizontal
- Nominal Panel Height
- 5 feet
- Actual Panel Height
- 60 inches
- Nominal Panel Width
- 6 feet
- Actual Panel Width
- 72 inches
- Proportional Split
- 4ft+1ft
- Color
- Clay
- Color Family
- Standard Solid
- Post Contact Type
- Soil or Concrete
- Warranty
- Transferable Limited Lifetime Warranty
- Features
- UV Protected, Water Resistant
- Material
- Vinyl (PVC)
- Origin
- United States 🇺🇸
